vellumplot is a declarative, pipe-first grammar of graphics built on the vellum backend. You describe a plot as an inspectable, serializable spec; nothing is drawn until the spec is compiled into a vellum scene and rendered.

Install

vellumplot compiles a Rust crate (inside vellum), so you need a Rust toolchain (cargo/rustc) on your machine alongside R. With that in place:

# install.packages("pak")
pak::pak("r-vellum/vellumplot")

A first plot

Start with vplot() on a data frame, then add a mark. Encodings (x, y, color, …) are tidy-eval expressions evaluated against the data.

library(vellumplot)

vplot(mtcars) |>
  mark_point(x = wt, y = mpg, color = hp) |>
  scale_color_continuous()

Printing a spec draws it into the plots pane (and embeds in a knitr/Quarto chunk), like ggplot2.

Layering marks

Add more marks to the same panel; scales train across every layer.

vplot(mtcars) |>
  mark_point(x = wt, y = mpg) |>
  mark_smooth(x = wt, y = mpg)

Faceting

Split into a grid of panels with shared or free scales.

vplot(mtcars) |>
  mark_point(x = wt, y = mpg) |>
  facet_wrap(~cyl)

The spec is just data

Nothing is drawn until the spec is compiled. summary() shows its structure without rendering.

summary(vplot(mtcars) |> mark_point(x = wt, y = mpg, color = hp))
#> <PlotSpec> 32x11 (11 columns), page 6x4 in
#>
#> ── layers
#> • mark_point(x = wt, y = mpg, color = hp)

Rendering to a file

render_plot() writes the compiled scene; the format follows the file extension.

p <- vplot(mtcars) |> mark_point(x = wt, y = mpg)
render_plot(p, "cars.png")

plot_svg() returns the scene as an SVG string, and plot_data_uri() inlines a plot as a self-contained data: URI (vector by default, or format = "png") for an <img>, a Markdown image, or an email — no separate file.


Inside a Quarto or R Markdown document you usually write nothing special: a plot printed in a chunk adapts to the target — a crisp inline SVG for HTML output, and the default vector/raster render for PDF or Word.

Where to next

Reference: every mark, scale, coord, facet, theme, and effect.
vellum: the graphics backend vellumplot compiles into.
vellumwidget: turn a scene into an interactive HTML widget.
vellumverse: install and attach the whole ecosystem in one step.
